The HDL-MC48IP-DMX.431 is a DMX show controller that supports DMX512, Art Net, and HDL Net protocols. It is designed to control RGB LED strips, RGB lights, and other DMX devices using 48 channels, with 48 areas and 99 scenes in each area.
DMX interface:
The HDL-MC48IP-DMX.431 is capable of handling any device that uses the DMX protocol. From RGB lighting units, to LED strips, and spot lights, all are easily controlled.
Up to 48 DMX channels:
In each of the 48 channels, 99 different scenes can be set. There are a total of 99 sequences available, each having 4 running modes, forwards, backwards, forwards & backwards, and random.
Functions:
- 48-channel, maximum 48 separate areas
- 0-99 scenes can be set in each area, each scene has up to 60 minutes of running time
- Total 99 sequences, 4 running modes are available for each sequence: forward, backward, forward & backward, random
- DMX512(1990 version)
- Supports Art net / HDL Net DMX protocol
- Low Threshold, High Threshold, Maximum Threshold are all available for each channel for different devices
- Each channel has Light protection delay time (0-25 seconds)
- Each channel has protection delay time for power On after power Off (0-60 minutes)
- Gateway between HDL Buspro and Ethernet
Electrical Parameters:
- Working voltage: DC12~30V
- BUS power consumption: 40mA/DC24V
- Signal interface: HDL Buspro, RJ45
- RJ45 connection:RJ45-UDP/IP network interface
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 72�90�66 (mm)
- Weight: 141.5g
- Housing material: Nylon, PC
- Installation: 35mm DIN rail installation
