The HDL-MSD08.40 dry contact input sensor has a total of 8 channels. The module is capable of accepting dry contact inputs, and supports both switching and dimming.
Dry contact sensor:
With an eight channel dry contact input, the HDL-MSD08.40 is the ideal dry contact management unit. In addition to its management functions it also has a tamper alarm to guarantee system security.
Diversified switch types:
To bring users even greater flexibility HDL engineers have made sure that an encompassing range of switch types are supported. The supported switches are mechanical, and push button. Various button modes are supported such as single on, single off, single on/off, combination on, combination off, and combination on/off.
Dimming:
This multifunctional switch also supports dimming, and can increase or decrease the light intensity in a variety of situations. This feature is of great benefit as it is able to create different lighting atmospheres via the level of illumination.
Various control types:
With one device control of scenes, sequences, universal switches and the broadcast of scenes and channels is possible. In addition to this control of lighting, curtains, panels, and SMS communication is enabled. To enhance building security the HDL-MSD08.40 can be connected to other security modules to create a complete security grid.
User-friendly:
Ease of use is central to any HDL device, and the HDL-MSD08.40 exemplifies this virtue. With a dedicated programming button, and a CPU status indicator, this unit can be installed and used almost instantaneously.
Functions:
- 8-channel dry contact input with tamper detection function
- Supported switch type: Mechanical Switch, Single on, Single off, Single on/off, Combination on, Combination off, Multi-function, Parallel switch
- Supported switch mode: Switch mode, dimmable two-way, dimmable increase, dimmable reduced
- Control Target type: Scene, Sequence, Universal Switch, Single channel lighting control, Broadcast Scene, Broadcast channel, Curtain Control, Panel Control, GPRS control, Security Module, TT player etc.
- Tamper-proof, need 1K Ohm resister in parallel to dry contact
- Security function, need to be used with the security module
- Supports online upgrading by HDL Buspro
Electrical Parameters:
- BUS power supply: DC12-30V
- BUS power consumption: 10mA/DC24V
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 45�45�16(mm)
- Weight: 45(g)
- Housing material: ABS
- Installation: Screw fix installation
- IP Protection: IP20
