TDX Frontend - DVB-S/S2 [QPSK/8PSK]
DVB-S/S2 input module - QPSK and 8PSK demodulator. The DVB-S module is able to receive a complete transponder.
All services on the chosen frequency will be transferred to the TDX pool.
Input frequency: 950-2150. Supports DiSEqC 1.1
Characteristics
Demodulator Type: QPSK/8PSK
Input level: 50 ... 85 dBµV
LNB V/H programmable: 0...13...18/300 V/mA
LNB LO/HI programmable: 0/22 kHz
DiSEqC level: 1.1
Electrical
Impedance: 75 Ω
Frequency
Input frequency range: 950-2150 MHz
Return loss
Input return loss: >10 dB
Operational
DC Operating voltage: 12 ± 1 VDC
DC Current consumption: OFF 150/ON max. 450 mA
Temperature - operating: -10...50 °C
Temperature - storage: -20 ..70 °C
Humidity - operating: 20...80 %
Humidity - storage: 10...90 %
Mechanical
Dimensions product (H x D x W): 29 x 132 x 50 mm
Weight (kg) TB(D): 0.08 kg
Net Weight: 0.075 kg
Tara Weight: 0.030 kg
Total Weight: 0.105 kg
