TDX Black Edition Main Unit is the ultimate choice when delivering reliable solutions to the hospitality sector,fully supporting upgrades and new installations.
The TDX Black Edition cabinet is designed with up to 16 input modules and 6 Quad output modules; it is extremely compact and can therefore be easily installed on a wall or in a 19 "rack. Whether it is related to the installation, maintenance or repair, all inputs, outputs and cables can be easily installed and operated from the front of the cabinet.
Up to three TDX Black Edition Headends can be combined as one system of input and output signals, as such up to 72 PAL, COFDM or QAM channels are possible (or 480 IP services). The new HTML5 user interface guarantees easy installation, remote control and system monitoring via SNMP.
DRM integration for secure HD-service distribution is supported and can be easily handled with the Simulcrypt interface.
With the PID-management the TDX Black Edition supports services changes without any retuning of TV's.
Characteristics
Max. LNB control: 4 x 305 mA
Output level max. @ 60 dB IMD - 24 combined channels 103: dBµV
Test Point: - 20 dB
Electrical
Impedance: 75 Ω
Frequency
Frequency range (RF OUT): 47...862 MHz
Mechanical
Dimensions product (H x D x W): 290 x 240 x 440 (6,5 HE) mm
Net Weight: 10.770 kg
Tara Weight: 1.360 kg
Total Weight: 12.130 kg
Remarks: SNMP version : V1 & V2c
Operational
AC Supply voltage: 190 - 260 (50/60) Hz VAC
Power Consumption (typ.): 280 (min. 20) W
Temperature - operating: -10...50 °C
Temperature - storage: -20 ..70 °C
Humidity - operating: 20 ... 80 %
Humidity - storage: 10 ... 90 %
Return loss
Return loss (RF OUT): > 14 dB at 47 MHz (-1,5 dB/octave; min. 10 dB) dB
Connectors
External RF OUT: F-connector
PC interface: RJ 45
SFP cage: 4x SFP Module (Cat5/Opto)
