The HDL-MD512-DMX.232 is a DMX show controller that supports DMX512, Art Net, and HDL Net protocols. It is designed to control RGB LED strips, RGB lights, and other DMX devices using 512 channels, with 16 areas and 1024 scenes in each area.
Up to 512 channels:
With 48 groups, and 512 scenes in each group the HDL-MD512-DMX.232 is the optimum choice for large applications. In each of the 512 scenes, 99 sequences can be programmed with up to 255 steps. These sequences have four running modes, Forward, Backward, Random, and Bounce.
Data Exchange Function:
Two way data exchange is made possible by the HDL-Buspro and an Ethernet connection. This intelligent data exchange system, reduces data traffic, increases communication stability, and ensures optimum efficiency.
Multi-protocol support:
The HDL-MD512-DMX.232 supports DMX 512, NET DMX, and Artnet DMX protocols. This multi support allows a user to use the modules and protocols that best fit their individual situation. Even though the module has triple protocol support the signal suffers no degradation or data loss.
Onboard LCD:
With a dedicated onboard LCD a user is able to instantly read the status of the SB-DN-512DMX. This enables faster configuration, installation, and minimizes time taken while trouble shooting.
Functions:
- It has up to 16 areas. Each area can set 0-1024 scene, and the scene’s running time is up to 60 minutes
- Total is 99 sequences, 4 running modes are available for each sequence: forward, backward, forward & backward, random
- DMX512(1990 version)
- Supports Art net / HDL Net DMX protocol
- Low threshold, high threshold, maximum threshold are all available for each channel for different devices
- Each channel has light protection delay time (0-25 seconds)
- Each channel has protection delay time for power on after power off (0-60 minutes)
- Gateway between HDL Buspro and Ethernet
Electrical Parameters:
- Working voltage: DC12~30V
- BUS power consumption: 200mA/DC24V
- Signal interface: DMX512 (1990)
- RJ45: RJ45-TCP/IP network interface
- Control channel: 512
- Ethernet network interface: 10Mbps/RJ45
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 144x90x66 (mm)
- Weight: 428.6g
- Housing material: Nylon, PC
- Installation: 35mm DIN rail installation
