An 8 meter detection range allows the MSPU03.4 to detect movement from afar, and the dual logic inputs allow flexibility during installation. The module can control 480 targets via its 24 logic blocks, and is capable of outputting both OR & AND logic states.
Ultrasonic sensor:
The HDL-MSPU03.4C is a ceiling mounted ultrasonic sensor with an 8 meter detection range, it is used to detect movement and transmit a signal to a target device enabling it to activate. The device can be quickly and simply installed via its screw or spring bracket, and has an adjustable sensitivity range.
Dual logic inputs:
Dual logic inputs can be used, giving immense versatility to end users. Coupled with this the unit has 24 logic blocks, with each block having 20 output targets. The output logic is OR & AND, with each logic state also having a universal switch and an auto shutoff function.
Multi sensor:
In addition to the ultrasonic sensor the unit can also gather data about the ambient temperature and brightness. The light sensor has a range from 0-500 Lux, making it suitable for all building environments.
Functions:
- Equipped with LUX sensor, ultrasonic sensor and universal switch, which can be used as logic conditions
- With two logic relationship: OR, AND
- Adjustable ultrasonic sensitivity, Sensitivity range:1-10
- 24 logic blocks in total, each logic block has 20 output targets
- Universal Switch 201 ? 248 can be used as logic inputs, two Universal Switches for each logic and they has auto-off option too (from 1 ? 3600 seconds)
- A Logic can trigger some targets when it is true, and trigger other targets when it is false
- Security function, to be used with the security module
- Supports upgrade from HDL Buspro
Electrical Parameters:
- BUS power supply: DC12-30V
- BUS power consumption: 30mA/DC24V
- Ultrasonic sensor range in diameter: 8m (Installation Height: 3m)
- Range for LUX sensor: 0-500lux
Approved:
- CE
- RoHS
Product information:
- Dimensions: 63(Diameter)�38(mm)
- Weight: 90.5(g)
- Housing Material: Infrared lens, ABS
- Installation: Ceiling mounted
- IP Protection: IP20
