The HDL-MC64-DALI.431 is a 64 channel DALI controller, with built in DALI power supply and single DALI bus. The unit can also support 64 DALI ballasts, and scene control. The scene control allows the creation of 16 areas, with each area having 16 scenes.
Up to 64 DALI devices can be operated for switching and dimming in 16 areas, every DALI device is designated an address automatically. This automatic identification saves time and enables a user to install the system faster.
Scene recovery:
After the power has been turned off the DALI controller is able to record the scene setting, when the power is turned back the last used scene is activated.
Set channel limits:
With channel limits, lighting is able to be set at its lowest or highest limits. These limits must be set within the limits of the MC64-DALI.431.
Short circuit protection:
In the unlikely event that the DALI BUS short circuits the 64 channel DALI controller will turn off to prevent any potential damage.
Customisable run time:
Each of the 16 scenes that the module can control have an adjustable run time from 0.7 seconds to 90.51 seconds.
Functions:
- Gateway between HDL-Buspro system and Dali Ballast
- Max. 64 channel Dali ballasts can be connected to this module
- With scene control
- Maximum 16 separate areas, supports area dimming
- Each area has 16 scenes and Maximum scenes running time is 90.51s
- Each channel can set low limit, high limit
- It has built in DALI power supply and it insulates with HDL-BUS
- You can choose specified scene or scene before power off when the device restarts
- Short circuit protection for DALI wires
- Supports HDL-Buspro online upgrading
Electrical Parameters:
- Power supply: DC15~30V
- HDL-BUS power consumption: 15mA/DC24V
- DALI BUS power: AC220V/AC110V
- Interface: HDL Buspro, DALI
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 72�90�66 (mm)
- Weight: 379.5g
- Housing material: Nylon, PC
- Installation: 35mm DIN rail installation
