XANTECH One Zone Four Source Conn. Block

Main features:

• Connects four emitter ports and power supply to all Xantech infrared receivers and keypads

• Four parallel emitter ports with 470-Ohm resistors drive four single or four dual emitters

• Quick-connect stereo mini jack for IR Receivers that use a stereo mini plug
• STATUS terminal for connection of IR Receivers and Keypads that have status LED's
• 2.1 mm coaxial power jack
• Requires either the 781ERGPS or 782ERGPS power supply
• Dimensions: 3" x 1 3/4" x 13/16" (77mm x 45mm x 21mm)
• Power LED
