The Whyte Series 5 WB WT52-10WB 10dB 2-Way Tap features our intelligent trunk equalisation technology Trunk EQ for flat trunk output. This industry first enables longer cascades to be created for Quattro or Wideband IRS distribution systems.
Main Features:
- Features Trunk EQ
- Inbuilt LTE filter
- LED power indicator
- Colour coded inputs and outputs
- Tap outputs on top of unit for easy access
- Auxiliary 18V Input injects power to SAT lines
Specifications:
Frequency: | SAT: 290-2340MHz TERR: 87-790MHz |
Inputs (F-Type Connector): | 4 SAT + 1 TERR |
Outputs (F-Type Connector): | 3× 4 SAT 3× 1 TERR |
DC Input (Injection of DC applied to): | All SAT Trunk and Tap |
DC Pass Trunk To Tap: | SAT: All TERR: No |
DC Pass Trunk to Trunk: | SAT: Yes TERR: No |
Trunk Through Loss: | SAT: 2dB±1 TERR: 2dB±1 |
Tap Loss: | SAT: 10dB TERR: 10dB |
Fixed Slope Tap: | YES |
Trunk EQ: | YES |
Isolation: | >30dB |
Max Current Pass (Trunk/Trunk Trunk/Tap): | 2A |
Power Indication: | LED |
Dimensions (mm): | 156 x 150 x 43 |
Weight: | 396g |
