The US-48 UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non-blocking throughput, the US-48 supports up to 70Gbps.
The US-48 features two SFP+ ports for high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high?performance storage server or deploy a long-distance uplink to another switch.
Switch Configuration:
You can access any managed UniFi Switch through the UniFi Controller to configure a variety of features:
- Operation mode (switching, mirroring, or aggregate) per port
- Network/VLAN configuration
- Jumbo frame and flow control services
- Network settings
- Storm control setting per port
- Spanning tree configuration
- 802.1x control and RADIUS VLAN
- Debug terminal option for command-line interface
Specifications:
- 48 x Gigabit RJ45 Ports
- 2 x SFP Ports
- 2 x SFP+ Ports
- 1 x Serial Console Port
- Rack-Mountable
Dimensions: 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
Operating Temperature: -5 to 40C (23 to 104F)
Non-Blocking Throughput: 70 Gbps
Switching Capacity: 140 Gbps
Forwarding Rate: 104.16 Mpps
Maximum Power Consumption: 56W
Sound Level: 0- 34dBa
Fan Level: 1- 37dBa
LEDs per Port: Speed/Link/Activity
Certifications: CE, FCC, IC
