The Ubiquiti EdgeSwitch ES-10XP is one of Ubiquitis most affordable managed switches that come equipped with SFP ports. The ES-10XP is optimised for WISP (Wireless Internet Service Provider) deployments featuring eight 24V Passive PoE Gigabit RJ45 ports for copper connectivity, perfect for powering AirMax AC devices and more. Two SFP ports offer fiber connectivity.
The EdgeSwitch 10XP offers top price/performance value, with the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, as well as an extensive suite of advanced Layer 2 switching features and protocols. For its total, non-blocking throughput, the EdgeSwitch 10XP supports up to 10 Gbps.
Ideal for WISP Applications- Eight Gigabit RJ45 ports offer copper connectivity with 24V PoE output, while two SFP ports offer fiber connectivity.
Optimised Power Consumption- The EdgeSwitch 10XP consumes 50% less power than the previous-generation EdgeSwitch XP, allowing for passive cooling.
Layer 2 Switching Capacity- The EdgeSwitch 10XP supports an extensive suite of advanced Layer 2 switching features and protocols.
Versatile Mounting Options- The EdgeSwitch 10XP can be mounted on a wall or in a rack (rackmount accessory, model ER-RMKIT, sold separately).
Simple UI- The new UI is easy to learn and allows you to monitor and configure features through its intuitive graphical user interface.
Centralised Management- The EdgeSwitch 10XP is supported and managed by UNMS (Ubiquiti Network Management System)
Features;
(8) Gigabit RJ45 Ports
(2) SFP Ports
Non-Blocking Throughput: 10 Gbps
Switching Capacity: 20 Gbps
Forwarding Rate: 14.88 Mpps
Supports 24V Passive PoE Output on All RJ45 Ports
Powered by External AC/DC Adapter
Wall- or Rack-Mountable*
Specifications:
ES-10XP
Dimensions 207 x 31.1 x 90 mm
Weight 500 g
Interfaces;
Networking
Management
(8) 10/100/1000 Mbps RJ45 Ports, (2) 1 Gbps SFP Ports
Ethernet In-Band
Power Method 24VDC, 2.5A
Power Supply 24VDC, 2.5A Power Adapter (Included)
Supported Voltage Range 9 - 30VDC/5A
Max. Power Consumption (Excluding PoE Output) 8W
LEDs;
System
RJ45 Data Ports
SFP Data Ports
Status
PoE/Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air: +- 24 kV, Contact: +- 24 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -10 to 50 C
Operating Humidity 5 to 95% Non-condensing
Certifications CE, FCC, IC
PoE Interface (8) 24VDC Passive PoE (Pins +4, 5; -7, 8)
Max. Passive PoE Wattage per Port 15W
24V Passive PoE Voltage Range 24V
*Use the optional ER-RMKIT for rack-mounting
