Using the Edge OS Platform this Layer 3 Managed Switch does do Routing so is more for tech savvy customers requiring higher end enterprise network applications. For just a Managed switch please refer to the new UniFi range of Layer 2 Managed switches.
The Ubiquiti EdgeSwitch 24 Port 250W Layer 3 Managed PoE Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with total non-blocking throughput of up to 26 Gbps.
An extensive suite of advanced Layer-2 switching features and protocols, and Layer-3 routing capability makes the EdgeSwitch ready for a wide variety of enterprise class uses. There are also two SFP ports supporting uplinks of up to 1 Gbps (Compatible SFP Module required).
The Ubiquiti EdgeSwitch has 24 Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V Passive PoE. By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V Passive PoE devices, it is possible to manually enable 24V passive PoE using the EdgeSwitch Configuration Interface.
Designed for convenient management, the EdgeSwitch Configuration Interface allows administrators to configure and monitor switch features in a graphical user interface.
For advanced users, an industry-standard command-line interface (CLI) is available through telnet and SSH.
This EdgeSwitch comes with 24 gigabit 802.3af/at active / passive PoE Ethernet Ports with a total of 250W available.
Product Features:
Layer 2 Switching and Layer 3 Routing Capability
PoE+ Support
Optical Fiber Backhaul
Technical Specs:
Dimensions: 485.04 x 44.45 x 285.6 mm
Weight: 3.7 kg
Total Non-Blocking Throughput: 26 Gbps
Switching Capacity: 52 Gbps
Forwarding Rate: 38.69 Mpps
Max. Power Consumption: 250W
Power Method: 100-240VAC/50-60 Hz, Universal Input
Power Supply: AC/DC, Internal, 250W DC
LEDs Per Port: RJ45 Data Ports: PoE, Speed/Link/Activity
SFP Data Ports: Speed/Link/Activity
Networking Interfaces: 24x 10/100/1000 Mbps RJ45 Ethernet Ports 2x 1 Gbps SFP Ethernet Ports
Management Interface: Ethernet In/Out Band
Certifications: CE, FCC, IC
Rackmount: Yes, 1U High
ESD/EMP Protection: Air: ±24 kV, Contact: ±24 kV
Operating Temperature: -5 to 40° C
PoE Per Port: 5 to 95% Noncondensing
PoE Interfaces: POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-); 24VDC Passive PoE (Pins 4, 5+; 7, 8-)
Max. PoE+ Wattage per Port by PSE: 34.2W
Voltage Range 802.3at Mode: 50–57V
Max. Passive PoE Wattage per Port: 17W
24V Passive PoE Voltage Range: 20-27V
