The Ubiquiti airMAX RocketDish 34dBi is a 5GHz Duplex MIMO, 30 dBi with dual polarization dish especially designed to be paired with a Ubiquiti Rocket Radio for long range PtP links. The Dish includes all mounting accessories and rocket pigtails.
Bi-polarisational 34 dBi antenna unit suitable for Rocket M5 (MIMO). It uses horizontal and vertical polarisation, which replaces two separate antennas and saves your costs associated with hiring location antennas.
The antenna is suitable for simple creation of PtP connections. It is supplied with waterproof accessories for interfacing with the Rocket M5.
Specifications:
- Frequency: 5.1 - 5.8 GHz
- Dimension: 1050 mm
- Gain: 30-34 dBi
- Polarisation: Horizontal and Vertical
- Max VSWR: 1.4:1
- Radiating angle - H: 3 degrees
- Radiating angle - V: 3 degrees
- F/B Ratio: 42dB
- Type of connector: 2x RP-SMA
- Impedance: 50 Ohm
- Weight 13.5 kg
