CATV optical transmitter with AGC (without Return Path)
1310 nm, Po 10 dBm
Produces an optical signal in the 1310 nm-window modulated by the input RF CATV signal (47 MHz - 1100 MHz). The optical output power is 10 dBm.
- Equipped with automatic gain control (AGC)
- Stable in terms of temperature, thanks to the laser temperature control circuit
- Perfect for RFoG / RF Overlay solutions
HIGHLIGHTS
- MATV-compatible: up to 1100 MHz bandwidth
- OMI (Optical Modulation Index) test point
- Optical power and laser temperature LED indicators
- MQW-DFB refrigerated laser
- AGC with operation LED indicator
- Wide range of input power values
- Optical power drop alarm
MAIN FEATURES
- Very low equivalent noise conversion
- Easy to install and use
- High energy efficiency
- SC/APC optical connectors, and F-type connectors for RF
RF PARAMETERS
RF frequency range (MHz): 47-1100
RF input level (dBμV/dBmV): 75-90 / 15-30
RF manual gain adjust (dB): 0 ... 14 (steps 2 dB)
CAG control (dB): 15
Flatness (dB): ±1
Return losses (dB): ≥ 15 (typ)
Impedance (Ohm): 75
CSO (CENELEC 42) note 1 (dB): 60
CTB (CENELEC 42) note 1 (dB): 60
C/N note 1 (dB): >52
OPTICAL
Laser (type): MQW-DFB cooled
Wavelength (nm): 1310+/-10
Optical power (dBm): 10
Optical return losses (dB): 50
GENERAL
RF connectors (type): F female
Optical connectors: SC/APC
Supply voltage (Vdc): 12-24
Power consumption (mA): 360-220
Operation temperature: -5…….45 ºC / 32…….113 ºF
