Optical transmitter (without Return Path)
1550 nm, Po 5 dBm
Produces an optical signal in the 1550 nm-window modulated by the input RF SMATV signal (47 MHz- 2400 MHz). The optical output power is 5 dBm.
Perfect for RFoG solutions, and as RF Overlay transmitter on GPON networks.
HIGLIGHTS
- SMATV-compatible: up to 2400 MHz input bandwidth
- RF input level control: optimization of the optical conversion quality parameters
- Optical power drop alarm
MAIN FEATURES
- Very low equivalent noise conversion
- Easy to install and use
- High energy efficiency
- SC/APC optical connectors, and F-type connectors for RF
RF PARAMETERS
Frequency range (MHz): 47 - 2400
Flatness: 47-1200 MHz ±0.5 dB / 950-2400 MHz ±2 dB
Impedance (Ohm): 75
Input level: RF 73 - 93 dBμV / SAT 63 - 83 dBμV
Manual gain adjustment (dB): 0 ... 14 (2dB steps)
C/N (dB): >51
CSO (dB): >60
CTB (dB): >60
OPTICAL
Laser (type): MQW - DFB
Wavelength (nm): 15500 ± 10
Output optical power (dBm): 5
GENERAL
RF connectors (type): “F” female
Optical connector: SC/APC
Consumption: 12 Vdc 270 mA / 24 Vdc 155 mA
Operating temperature: -5 ... +45 ºC
