CATV optical transmitter with AGC (without Return Path)
1550 nm, Po 10 dBm
Produces an optical signal in the 1550 nm-window modulated by the RF input signal (47 MHz - 1100 MHz). The optical output power is 10 dBm.
Equipped with automatic gain control (AGC). Furthermore, it is stable in terms of temperature, thanks to the laser temperature control circuit. Perfect for RFoG solutions, and as RF Overlay transmitter on GPON networks.
HIGHLIGHTS
- MATV-compatible: up to 1100 MHz bandwidth
- OMI (Optical Modulation Index) test point
- Optical power and laser temperature LED indicators
- MQW-DFB refrigerated laser
- AGC with operation LED indicator
- Wide range of input power values
- Optical power drop alarm
MAIN FEATURES
- Very low equivalent noise conversion
- Easy to install and use
- High energy efficiency
- SC/APC optical connectors, and F-type connectors for RF
RF PARAMETERS
RF frequency range (MHz): 47-1100
RF input level (dBμV/dBmV): 90 / 30
RF manual gain adjust (dB): 0 ... 14 (steps 2 dB)
CAG control (dB): 15
Flatness (dB): ±1
CSO (CENELEC 42) note 1 (dB): 60
CTB (CENELEC 42) note 1 (dB): 60
OPTICAL
Laser (type): MQW-DFB cooled
Wavelength (nm): 1550 ±20
Optical power (dBm): 10
GENERAL
RF connectors (tipo): F female
Optical connectors: SC/APC
Supply voltage (Vdc): 12-24
Power consumption (mA): 360-220
Operation temperature: -5 … +45 ºC / 23 ... 113 ºF
