TELEVES Kompact Launch Amp
This is a one input port amplifier based on a split-band amplification philosophy (UHF & VHF) and independent attenuators, (UHF interstages attenuator for a low noise figure).
It is enclosed into a robust diecast chassis and intended for the distribution of digital terrestrial signalsand has DC bypass switches in both the input and output.
Band (MHz): 47-862
Gain (dB): 41-53
Maximum outpput level (DIN 45004B) (dBuV): > 123
Noise Figure (dB): 10
Attenuator (dB): 0-20
Mains voltage (V~): 196-264
Max. AC power consumption (W): 23
Power consumption (mA): 350 (24V=)
Max. DC bypass input and/or output (mA): 700 max. (24V=)
Protection level: IP30
