SHELLY 4CH DIN Rail Relay Switch with WIFI

Lan & Bluetooth Connection

SKU: SHELLY PRO 4PM

  Product Documents

SHELLY 4CH DIN Rail Relay Switch with WIFI

Lan & Bluetooth Connection


Professional 4 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.

Main features:

  • LAN, Wi-Fi, and Bluetooth connection
  • 4 outputs, 16A each. Total device maximum of 40A
  • Precise power metering
  • Overpower and overvoltage protection of the load.
  • DIN rail mountable
  • 1.8-inch color screen with navigation keys
  • Power supply AC: 110-230V ±10%, 50/60Hz
  • Maximum load: up to 16A per channel with up to 40A for the whole device
  • Channels: 4 Channel
  • Device temperature protection
  • Overload protection
  • Power measurement
  • HTTP/HTTPS webhooks
  • Custom scripts (mJs)
  • Operational temperature: 0°C to + 40 °C
  • Device power consumption: < 4 W
  • Intelligent On/Off
  • Local and remote control
  • Sunrise/Sunset
  • Weekly Schedule
  • UL Listed option
  • Wireless
  • Wi-Fi Protocol: 802.11 b/g/n
  • Wi-Fi Radio frequency: 2412 - 2484 MHz
  • Wi-Fi Radio signal power: 1mW
  • Wi-Fi Range: up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
  • Bluetooth
  • Ethernet
  • Size:90mm x 52mm x 57mm
