The RUIJIE Wireless Bridge PTP Kit 2.4GHz, the RG-EST100-E, a dual-stream wireless bridge that effortlessly transmit data across distances of 500m in real-time.
Key Features:
- RG-EST100-E can easily transmit data from 500 m away in real time
- Factory-free configuration, without complex alignment
- IP55 Weatherproof, -30°C~60°C guarantee stable operating at outdoor environment or elevator environment
- Support maximum 10 x 3 MP cameras loading at 100 m, 5 x 3 MP cameras loading at 500 m
- Visually Intuitive statistics monitoring on Ruijie cloud, easy remote maintenance
Technical Specifications:
- Operates on a 2.4 GHz Single-Band Dual-Stream radio design.
- Utilises IEEE 802.11b/g/n transmission protocol.
- Works within an operating band of 802.11b/g/n: 2.400 to 2.483GHz.
- Uses directional antennas with an 8dBi gain.
- Facilitates polarisation horizontally and vertically at 70°.
- Recommended bridging distance: 500m (optimal).
- Employs 2x2, MU-MIMO spatial streams.
- Designed with 64 MB of memory and 8 MB flash.
- Maximum throughput of up to 300 Mbps at 2.4 GHz.
- Maximum adjustable transmit power of ≤100 mW(20 dBm).
- IP55 rated, with ±6 KV (Common Mode) lightning protection.
- Can be mounted on both walls and poles.
- Dimensions 165.5mm x 68.7mm x 42mm
- CE Certified.
RUIJIE's wireless kit offers exceptional range, weather-proofing and camera loading capacity, all packaged in a practical and compact design. Ideal for outdoor or elevator set-ups and remote maintenance.
