RUIJIE Wireless Bridge Base PtMP is a robust wireless network solution providing extended transmission range, enhanced connectivity, and superior environmental protection.
Key Features:
• Exceptional wireless transmission range covering a maximum of 10km.
• Maximum of 1:32 PTMP links, allowing for easy pairing within 30 seconds.
• Dual GE ports included to enhance connectivity options.
• Provision for 24 V Passive Power over Ethernet (PoE) and 12 V DC Input, opening scope for solar power supply integration.
• Enhanced stability against harsh environmental conditions is provided by IP55 rating,
Technical Specifications:
• Dimensions: 200 × 98.5 × 29 mm (7.9 x 3.9 x 1.1 in.)
• Working Distance: Increases with external antenna • Capacity: 5 GHz, offering 867 Mbps
• Number of PtMP CPE: Ranging from 1 to 32
• Ports: Two 10/100/1000 Mbps ports available
• IP Rating: IP55, ensuring high durability
• Operational Temperature: –40℃ to +80℃ (–40°F to +176°F)
• ESD: ±24 kV for both Contact/Air
• Surge Protection: 6 kV
• Power: Supports 24 V Passive PoE, 12V DC input
• LED: Three for signal strength, two for LAN, one for system
• Pairing Method: One-touch pairing in 30 sec, App pairing in 2 minutes
Product Overview: Our RUIJIE Wireless Bridge Base PtMP is a robust wireless network solution providing extended transmission range, enhanced connectivity, and superior environmental protection.
