Optical In, Remote Monitor, Dolby AC3DD+
Frequency Range: TV and CATV TUNER, extended band, 4-1250 MHz; SAT TUNER, extended band, 930-2.610 MHz; GSM extended band, 860-1.000 MHz for telephone repeater installation
Input Impedance: 75 ohm (interchangeable “F” connector)
Digital Measurements: Digital Power, MER, BER, PER, LDPC, BCH, Noise Margin, MER versus CARRIER
Analog Measurements & Picture: Analog level, V/A ratio
Power range Measurements: TV 28 to 130 dBμV, SAT 30 to 130 dBμV
Net-id on board: Net-id, NID, TSID, LCN, SAT Orbit Position
Fast spectrum with MAX HOLD: full spect. capabilities with memory peak, variable span and automatic reference level
Constellation: for TV/CATV and SAT signals
Echoes, Pre-echoes, Micro-echoes: Representation in real Time
Quality: Digital Auto quality Test: PASS-MARGINAL-FAIL
Digital Pictures: MPEG2-4 SD & HD pictures with Program List, Audio Video PIDs,LCN, Video bit Rate all on one screen
TV Memory plan: World Wide countries with related channels plans pre-memorized
SAT Memory Plan: More than 2.000 transponders prememorized for world wide Satellite
Manual Memory Plan: Programmable TV, SAT (or combined TV/SAT) by PC or Local Keyboard
Loggers: TV, SAT & combined with stop & go function
Audio: AAC supplied, DOLBY (opt.)
Optical Power meter: with SC connector for fiber optic testing (FTTH & FTTX)
Free SMART PC interface program and FW upgrades
9” TFT TOUCH display: 16:9 high resolution
DC voltage at RF input: 5 – 12 – 18 – 24 V, DiSEqC, SCR and dCSS
Battery: Li-Po battery pack, 3 h duration & Battery Test function
Power supply & Battery charger: 12 Vdc, 2A
USB PC Interface: For SW upgrade on-line and memory plan management
USB PC Interface: For storage memory stick
Housing: Metal box and bag elite. Padded bag optional
Weight: only 1,8 Kg
Size: H 27,0 x W 15,5 x D 4,0 cm (meter only)
Note *: All technical specifications are subject to change without prior notice. Some options must be requested when ordering the instrument.
