The fibre system can be connected to either an optical converter in the home (to supply all the required TV services), or connected to an optical receiver to deliver services over an integrated reception system. Planar light wave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features a small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity. It is widely used in PON networks to realize optical signal power splitting.
These PLC Splitters come in standardised “LGX” (Light Guide Cross Connector) dimensions adding flexibility for interchangability within other industry standard LGX products.
Technical specification
- Low Insertion loss and Low PDL
- Compact Design
- Good channel-to-channel uniformity
- Wide Operating Wavelength 1260nm to 1650nm
- High Reliability and Stability
Parameters - 1x2
Operating Wavelength (nm) - ~1260-1650
Insertion Loss (typ.) (dB) - 3.7
Polarisation Dependent - 0.3 Max
Return Loss (dB) - >55
Connector Type - SC/APC
Weight (g) - 95
Dimensions (mm) - 130x113x25
