The EoC Ethernet WiFi Endpoint, with dual band concurrent Wi-Fi, is used in conjunction with the Triax Ethernet over Coax Controller (EoC) and is intended to provide Wi-Fi access in rooms without Coax cables. This is often the case for rooms such as conference rooms, corridors, lobbies, bars, etc.
The PoE Access Point is powered via Ethernet (PoE) to make the installation easy and independent of a power outlet.
This will require the installation of a e PoE+ compliant Ethernet switch connected to the EoC Controller.
The PoE Access Point also has a PoE output (passthrough) to supply power to other PoE devices. This could be a 2nd PoE Access Point, an IP phone, a Camera or other devices in the same room. If If the PoE output is not used, the AP can be switched to power save mode to accept a reduced PoE input power.
MAIN FEATURES:
- 2.4 GHz Wi-Fi : 802.11b/g/n MIMO
- 5 GHz Wi-Fi : 802.11ac MU-MIMO
- 2x Ethernet port
- PoE input: PoE-in 802.3af / PoE+in 802.3at
- PoE output: PoE-out 802.3af
- VLAN support
- Layer 2 Isolation
- Powersupply requirements:
- PoE (802.3af) 15.4W when NO PoE powered device on PoE output (Ethernet 2)
- PoE+ (802.3at) 30W when PoE powered device on PoE output (Ethernet 2)
CHARACTERISTICS
Wi IFI: Standard 802.11g/n @2.4GHz 2x2 - 802.11n/ac @5GHz 2x2WPA/WPA2 (personal or enterprise)TkIP/AES-CCMP cipherLayer 2 Isolation / Channel width: 5GHz: 20/40/80MHz - 2.4GHz: 20/40MHz / PHY rate: 867Mbps @5GHz - 300Mbps @2.4GHz / Max Clients: 200
TX power EIRP / frequencies: Europe (ETSI) :< 20.0 / 100mW (@2412...2472MHz - Ch. 1...13)< 23.0 / 200mW (@5150...5350mHz - Ch. 32...68)< 30.0 / 1000mW (@5470...5710MHz - Ch. 96...140)
OPERATIONAL
Ethernet Interface: 10/100/1000
AC Supply voltage: 100...240 @50/60Hz VAC
Power Consumption (typ.): 10 (28W@PoEout) W
DC Current consumption: 750 @13.5Vdc (PoEout: 2100mA @13.5Vdc) mA
PoE out: max. 15.4W (802.3af)
PSU/adapter Art number: 383801
Temperature - operating: -10...40 °C
Temperature - storage: -20 ..70 °C
Humidity - operating: 20...80 %
Humidity - storage : 10...90 %
ELECTRICAL
Ethernet interface standard: PoE-in 802.3af/at
Impedance: 100 Ω
MECHANICAL
Dimensions product (H x D x W): 37 x 119 x 185 mm
