The optional HDMI Cable Test Module enables ProAV integrators to easily evaluate cabling compatibility to the HDMI standard – including bandwidths (48 / 18 / 9 / 4.5Gbps), resolutions (HDR, UHD, HD), passive cable wiring quality, pin connectivity, and CEC support. The addition of these modules to MSolutions’ industry-leading HDBaseT testing device, offers an end-to-end ProAV testing solution from source to sink with its efficient, time-saving HDMI cable testing modules.
Key Features:
- Expansion module for the MS-TestPro 104B
- Adds capability for HDMI Cable testing on the MS-TestPro MS-104B
- Test passive cables for Standard, High-Speed, 18Gbps and Ultra High-Speed (48Gbps) compliance
- Quick, simplified HDMI cable troubleshooting
- Expands testing coverage for integrators – save time and money
- Verifies support for HDMI2.x Ethernet and HEAC
- True 19-pin test for all connections on a HDMI cable
- Fast report generation in .pdf format
- Future-proofed for 8K testing (future firmware update)
Specifications:
- HCT & Looper modules to fit into MS-104B MS-TestPro tester
- HCT module dimensions (W x D x H): 60mm x 84mm x 25mm
- HCT module weight: 0.1kg
- Looper module dimensions (W x D x H): 60mm x 33mm x 25mm
- Looper module weight: 0.1kg
- Operating temperature: 32°F to 104°F (0°C to 40°C)
- Storage temperature: -4°F to 140°F (-20°C to 60°C)
- Operating humidity: 0-80% non condensing
Package Contents:
- 1 x HDMI Cable Test Module
- 1 x Looper Module
