Alternative to Belden 8723 this cable has two pairs of 22awg with each pair individually foil screened to reduce cross talk. Commonly used for CCTV in the security industry as well as computer and instrumention applications. This cable features a high level of screening to reduce external interference.
The cable is suitable for installation in public buildings and is CPR classified to Cca s1a, d0, a1 and ideal for installs requiring compliance to BS6701.
| Alternative to Belden | 8723 |
|---|---|
| Conductor Material | Tinned Copper |
| AWG Size | 22 AWG |
| Number of Pairs | 2 |
| Insulation Material | Solid PE |
| Screening Type | Individually Foil Screened Pairs |
| Sheath Material | Low Smoke Non-Halogen |
| Sheath Colour | Grey |
| Flame Retardancy | BS EN 60332-1-2 |
| Low Smoke Emissions | BS EN 61034-2 |
| Halogen Gas Emissions | BS EN 60754-1, BS EN 60754-2 |
| CPR Classification | Cca s1a, d0, a1 |
| Overall Diameter | 4.3 mm |
