The HDL-MASTH.2C combines the functionality of a humidity sensor, temperature sensor, and Lux sensor into one simple to operate unit. The module then transmits the data gathered back to the HDL Buspro system, allowing efficient monitoring and management.
Triple sensors:
The triple sensor combination allows a user to monitor temperature, luminosity, and humidity levels. Logic condition inputs are available in the form of 2 dry contact inputs, which extend the scope and functionality of the HDL-MASTH.2C.
Multiple logic controlled applications:
The application can be created as transmitting the status to HDL Buspro system to warn the house owner, or to close the door & window or to switch on the dehumidifier when dry contact report window or door keeps open status in humid climate. 24 logic blocks with OR & AND logic relations enable to manage different applications.
Security integration:
The HDL-MASTH.2C can be seamlessly integrated with HDL security solutions. This is made possible by the modules two dry contact inputs, these inputs could be connected to door or window. In case the door or window keeps open for some time, the dry contact can send signal to trigger the HDL security system.
Functions:
- Built-in LUX sensor, temperature sensor, humidity sensor, 2 channels dry contact inputs, 2 universal switch, Logic
- 2 logical relations: OR, AND
- It has 24 logic blocks, the output is to control the targets
- The range of universal switch number in logic function is 201-248, each logic has 2 universal switch numbers.
- Multiple control targets: scene switch, sequence switch, universal switch, single channel lighting control, broadcast scene or channel , curtain switch, GPRS, panel control, security, music play etc.
- Supports upgrade from HDL Buspro
Electrical Parameters:
- BUS power supply: DC12-30V
- BUS power consumption: 25mA/DC24V
- Range of temperature sensor: -20℃~36℃
- Range of LUX sensor: 0~5000Lux
- Range of humidity sensor: 20℃~95℃
Approved:
- CE
- RoHS
Product information:
- Dimensions: 80(Diameter)×32(mm)
- Weight: 92.5(g)
- Housing material: ABS
- Installation: Ceiling mount
- IP Protection: IP20
