The HDL-MRDA0610.432 is a multifunctional dimming unit. It is capable of controlling multiple load types, and can support 6 channel inputs and outputs. Manual control is available on the unit itself, this makes instant system manipulation possible.
Dual outputs and functions:
The ability to output 10V for ballast dimming and a 10A relay output switching function, make this unit truly multifunctional.
Load types:
Both 10V LED lights and 10V fluorescents, can be controlled and dimmed with the MRDA0610.432. Each Relay channel is capable of connecting up to 30 dimmable ballasts and powering them on or off.
Brightness value:
Change the brightness of lighting in incremental stages. Exact light intensity requirements can be met, at 0.1V the lighting is at 1% brightness, and at 10V the lighting is at 100% brightness.
Manual Control:
With the ability to bypass the main control interface and manually control each channel, this ballast dimmer gives unparalleled end user control.
Scene Recovery:
When the dimmer has been powered off, it is able to automatically restore the last scene used when it is powered on again. This gives the user a system that remembers their previous scene, and requires no further control.
Functions:
- Up to 6 separate areas, max 12 scenes in each area
- Up to 6 sequence, each sequence has 12 steps, running time for each step is 60 minutes, the sequence has 4 running modes: 'forward', 'backward', 'forward and backward' 'random'
- Low, high, max threshold for each channel, suitable for different load
- Bypass button for manual control available for each channel
- You can select specified scene or scene before power off when device restarts
- Easy programming mode is available
- Supports HDL Buspro online upgrading
Electrical Parameters:
- Bus Working Voltage: DC15~30V
- Bus Power Consumption: 30mA/DC24V
- Relay Channel Output: 6CH/10A
- 0-10V Output: 6CH/10mA (Total current is less than 100mA)
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 144�90�66 (mm)
- Weight: 449.5(g)
- Housing material: Nylon, PC
- Installation: 35mm DIN rail installation
