17-input cascadable multiswitch with 16 output taps; DIP switch to select active and passive TV gain.
Main Features:
- Satellite band up to 2300MHz.
- High output level to cover long cable distances(60m with 6.7mm cable).
- Each port has an LED to show correct reception of DiSEqC commands.
- Return channel included when TV gain is passive (5-65MHz).
- When TV gain is passive, the product is fully powered by the receivers, the power supply only serves to power the active TV gain, other amplifiers and LNBs.
- External PSU1340TS power supply (13V, 4A) with Male Jack connector (2.1x5.5x12; inside positive, outside negative) not included in the package; to optimise installation space and reduce maintenance time.
- Small size due to matrix switching system, with connectors on both sides.
- Easy to install due to standard input colouring
