Pre-assembled band IV periodic Log Antenna characterized by extreme ease of installation thanks to the F connector placed near the pole attachment.
Main features:
- Installation of the the antenna in both polarization, vertically and horizontally without adapters or other accessories.
- Special connection of the dipole which guarantees contact reliability over time.
- Excellent mechanical resistance for fixing the elements to the cradle, excellent mechanical resistance to rotation on the pole, good electrical performance.
- The F connector is protected by a connector cover with bayonet coupling.
- Black antenna
Elements n °: 8 + 8
Band: 4
Channels: E21-E37
Bandwidth MHz: 470-606
I earn dBi: 10
Forward / backward ratio dB: 32
Loss of reflection dB: -18
Beam width (-3dB) °: ± 28
Wind resistance 120 Km / h (720N / m²) kg (N): 2.8 (27.46)
Connector Guy: F.
Impedance Ohm: 75
Maximum pole connection diameter (Ø) mm: 60
Dimensions (L x H) cm: 99 x 32
Multiple packaging quantity Pcs: 60
Unit weight kg:0.60
Total weight of multiple packaging kg: 38.0
Accessories
Horizontal polarization: Included
Horizontal zenith adjustment: PV10 (210011)
Vertical polarization: Included
Vertical zenith adjustment: PV10 (210011)
