ELAN® AV HDBaseT™ 8x8 Matrix

The ELAN HDMI Video Matrices offer unprecedented performance and value for the custom installation market. The EL-4KM-V88 is a 4K HDCP 2.2 8x8 matrix with a combination of 6 x HDBaseT and 2 x HDMI Outputs. This allows for cost effective integration of local displays and AV receivers within an installation. The matrix delivers HDMI, Bi-directional IR and PoH (PoE) up to lengths of 70m over a single CAT cable. The matrix can be controlled and configured using the built-in web interface module or ELAN Configuration Software, allowing the user to define HDMI outputs, HDMI inputs, and designate EDID presets.

Main features:

• Features 8x HDMI inputs which can be independently routed to 8 outputs (6x HDBaseT + 2x HDMI)
• Extends HDMI 1080p up to a distance of 70m over single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Web interface module for control and configuration of Matrix
• Bi-directional IR from all input and output locations
• Includes 8 x 5v-to-12v IR converter cables for IR InputsControl via front panel , IR, RS-232 and TCP/IP
• Supports PoH (Power over HDBaseT) to power compatible HDBaseT receivers
• 3rd Party drivers available for all major home control brands
• Advanced EDID management
• HDCP 2.2 compliant1
• U Design for 19" rack mount integration - Mounting kit included
