Designed to make recessed installations as simple as possible, this adjustable mount can be used to create recessed installations in landscape and portrait format. The BT8301 has a low profile design which is ideal for mounting into walls with a shallow recess, a pop-out system enables a quick and easy access to the rear of the mounted screen for servicing and maintenance and +/-4mm micro adjustment makes accurate screen alignment quick and easy.
Features:
- Slim design ideal for low profile installs on walls or in shallow recesses
- Modular mount allows videowall assembly in an unlimited number of configurations
- Suitable for landscape or portrait screen mounting
- Push to open / push to close system provides quick and easy service access
- Tool-less micro-adjustment of +/-4mm at each corner for seamless display alignment
- Lateral adjustment of screen once mounted
- Compatible with B-Tech's collar and pole system for pole mounting screens
- Safety screws help prevent unauthorised removal of screens
- All mounting hardware included
Specifications:
- For screen sizes: 42" (106cm) - 70" (177")
- Max load: 35kg (77lbs)
- VESA® compatibility: up to 600 x 400*
- Universal fixings: up to 442 x 436mm (17.5" x 17")
- Depth flat to the wall: 77.5mm* (3") (+/-4mm (0.16") with micro-adjustment)
- Depth popped out: 260mm* (10.2") (+/-4mm (0.16") with micro-adjustment)
- Screen height adjustment: +13mm (0.5")
*Please note using the included Interface Adaptor Arms to mount VESA 600 x 400
screens will increase the total depth of the product by 6mm, for a total depth of
83.5mm, or 260mm whilst popped out (+/-4mm micro-adjustment).*
