The BT7885 is a screen mounting solution with an integrated pull-down tray for storing AV equipment behind the screen. Featuring a quick release equipment interface plate which can be separated from the mount, AV equipment can be easily added or removed from the install without needing to remove the screen first. The tray mechanism is tool-less for ease and speed of use, with the option to add a padlock (not included) to help prevent unauthorised access to the equipment. To ensure cables do not get tangled or pinched when the tray is opened and closed, an integrated cable management track moves in unison with the tray. The BT7885 is suitable for wall mounting as well as to B-Tech’s System 2 poles and System X/Mode-AL columns.
Flat screen mount designed to hold & hide AV accessories
Tool-less, operation & assisted release of the AV storage tray
Accessories can be accessed without screen removal
Interface arms include levelling screws to adjust the screen height
Locks in closed & open positions & can be secured with a padlock (not included)
Keyhole wall mounting for easy installation
Locks in closed & open positions & can be secured with a padlock (padlock not included)
Compatible with B-Tech's System X, Mode-AL columns & B-Tech collars
for pole mounted installations
Additional trays available for purchase to allow for fast change over of AV equipment
All mounting hardware included
Recommended Screen Size: 49" (124cm) - 86" (218cm)
Max screen weight: 70kg (154lbs)
VESA fixings: up to 100 x 100 - 600 x 400
Depth from wall: 100mm (4")
Max equipment dimensions: H:361mm (14.2") W:575mm (22.6") D:60mm (2.4")
Max tray extension (from top of mount): 1192mm (47")
