Features:
- Compatible with 19" rack mountable products
- Added ventilation around the cabinet
- Top & bottom cable entry
- Rear plastic cable entry
- Toughened glass front door
- Plastic locking mechanism (latches on side panels)
- Barrel locking mechanism (front door)
- Earthing terminals
- Integral cable management in mounting profiles
- Numbered and adjustable mounting profiles
- Grommets on base thus avoiding direct contact with an abrasive surface if cabinet is not wall mounted
Dimensions:
Size: 12U
Width: 565mm
Height: 576mm
Depth: 600mm
Loading Capacity:
40kg
Material:
Steel Construction
• Main body: 1mm
• Side panels: 1.2mm
• Front door: 1.2mm
• Vertical rails: 1.5mm
• Finish Surface: Powder Coating
• Colour Code: RAL9005
Side Panel Lock System
Removable and lockable side panel simplifies and secures your installation, comprising of Barrel Lock and sliding spring latch mechanism.
Plastic Cable Entry
The standard configuration of the CAB6WB550 has a plastic knock-out cable entry on the rear.
19’’ Device Mounting Rail
Internal numbered uprights with additional built in cable management. Using standard M6 cage nuts.
Front Door
Can be mounted on the left or right hand side using the simple spring latch fixing posts at the top. Durable Fixed grommet rings are used to keep the door on a smooth hinge on the bottom.
