The Hub 2 intelligent control panel is a key element of the Ajax security system. The device monitors operation of all Ajax detectors and immediately sends an alarm signal to the owner and the Central Monitoring Station. The device collects information on detector operation in an encrypted format, analyzes the data, and in case of alarm, notifies the system owner and the Central Monitoring Station in just milliseconds. It is set using the mobile application, and the detectors are connected with just one click. It can be mounted in just a few minutes using the SmartBracket mount.
Main features:
- Connect up to 100 devices to the hub
- Up to 50 users per hub
- Supports the MotionCam
- Connects using ethernet or 2 Micro-SIM's
- Grade II rated
- Checks in with devices every 36 seconds (other systems tend to check in every 20 minutes)
h) for up to 16 hours of offline operation when power is switched off
- Compatible with iOS and Android
Installation: Indoors
Connected devices: 100
Video surveillance support:Up to 25 cameras or DVRs
Users:50
Rooms: 50
Security groups: 9
Connected ReX: 5
Connected sirens: up to 10
Scenarios: 32
MotionCam detectors support: +
Communication channels: Ethernet / Two 2G SIM-cards
Alarm signals: Delivery time: 0.15 sec / Notification types: SMS, call, push-notification
Switching between the SIM-cards: 4 minutes
CMS connectivity: CMS connectivity: Contact ID, SIA (DC-09) / CMS software supporting visual alarms verification
The speed of alarm delivery to the CMS: Instant
Operating system: OS Malevich
Power supply : 110-240 V with pre-installed battery / 12 V with alternative 12V PSU power supply /6 V with alternative 6V PSU power supply / Energy consumption from the 110-240 V grid - 10 W
Built-in back-up battery: Li-Ion 2 А·h /Ensures up to 16 hours of operation when using SIM card only
Jeweller radio technology
Communication range with detectors - up to 2,000 m in an open space
Two-way communication between devices
Operating frequencies - 868,0 - 868,6 MHz
Self-adjusting RF output power - up to 25 mW
Block encryption based on AES algorithm
Detector polling period - 12−300 s
Frequency hopping
Wings radio technology: Transmission of visual confirmations / Delivery verification of packages
Operating temperature range: From −10°С to +40°С
Size : 163 × 163 × 36 mm
Weight: 362 g
Warranty: Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
Service life : 10 years
Complete set: Ajax Hub 2 intelligent control panel / SmartBracket mounting panel / Power cable / Ethernet cable / Installation kit /SIM card depending on region) / User’s guide
