2N® Access Unit 2.0 Touch Keypad & RFID

125kHz 13.56MHz NFC PICard Compatible
5 Year Warranty
*Special Order! NCNR - Check Lead Time*

SKU: 9160346

  Product Documents

2N® Access Unit 2.0 Touch Keypad & RFID

125kHz 13.56MHz NFC PICard Compatible
5 Year Warranty
*Special Order! NCNR - Check Lead Time*


Do you need a good-looking access reader for your project? All the residents of luxury residences will be delighted with the 2N Access Unit 2.0. Select modern access with a mobile phone or fingerprint. Do you prefer conventional methods? We also offer an RFID card reader or keypad. Cannot decide? Select a combination of several methods in one device. But don’t look for controllers in our portfolio. They are already an integral part of every reader.

  • Ideal for residential projects
  • Fastest Bluetooth technology
  • You don’t need a controller
Interfaces
Power supply:PoE and/or 12 V/1 A DC
PoE:802.3af (Class 0–12.95 W)
LAN:10/100BASE-TX with Auto-MDIX, RJ-45 modular jack
 (2N® Access Unit Bluetooth has terminal block or pigtail RJ-45)
Recommended cabling:Cat-5e or better
Active switch output:8 to 12 V DC/max 600 mA
Passive switch:NO/NC contacts, up to 30 V/1 A AC/DC
Inputs:2 inputs - in passive/active mode (-30 V to +30 V DC)
 (2N® Access Unit Bluetooth has 3 inputs)
 OFF = open or Uin> 1.5 V
 ON = short-circuit or Uin< 1.5 V
Tamper switch:native part of the 2N Access Unit 2.0
Audio:buzzer (97dBA)
Supported protocols:DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog
Bluetooth Reader
Version:compatible with Bluetooth 5.0 LE
Range:(short - typically up to 3m*, long - typically up to 10m*)
*distances should serve only as an approximate guide and may vary depending on the phone model and installation environment
Security:RSA-1024 and AES-128 encryption
RX sensitivity:
Mode:
up to -93 dBm
touch, tap in app
Mobile Application Support
 Android 6.0 and higher, iOS 12.0 and higher
RFID Card Reader
Supported frequencies125 kHz variant
 13.56 MHz variant
 125 kHz and 13.56 MHz variant
Supported card typescard type compatibility depends on Order No.
125 kHzEM4xxx
 HID Prox – versions with 125 kHz support and S in Order No. Only
13.56 MHzISO14443A, PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key)
 reads UID (CSN) and secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
Secured 13.56 MHzISO14443A (MIFARE® DESFire®), PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key), HID SE (Seos, iClass, MIFARE SE)
 reads secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
 reads PACs ID (HID iClass cards with SIO object)
Touch Keypad
Technology:capacitive touch technology
 high touch layer sensitivity (0.1pF)
Reliability:regular automatic calibration (SmartSense Auto-tuning)
 does not detect false touches on wet surface
Signalling:configurable backlight intensity
 indication using multicoloured LEDs
 acoustic response for every keypad touch
