Stay flexible. Traditional and modern method of access control in a single reader. The 2N® Access Unit 2.0 Bluetooth & RFID reads both frequencies of RFID cards – 125 kHz and the smart 13.56 MHz. The users can also authenticate with their mobile phone. All they need to do is switch on Bluetooth and install the 2N® Mobile Key application. They can leave their phone in their pocket and simply tap the reader.
| Interfaces | |
| Power supply: | PoE and/or 12 V/1 A DC |
| PoE: | 802.3af (Class 0–12.95 W) |
| LAN: | 10/100BASE-TX with Auto-MDIX, RJ-45 modular jack |
| Recommended cabling: | Cat-5e or better |
| Active switch output: | 8 to 12 V DC/max 600 mA |
| Passive switch: | NO/NC contacts, up to 30 V/1 A AC/DC |
| Inputs: | 2 inputs - in passive/active mode (-30 V to +30 V DC) |
| OFF = open or Uin> 1.5 V | |
| ON = short-circuit or Uin< 1.5 V | |
| Tamper switch: | native part of the 2N Access Unit 2.0 |
| Audio: | buzzer (97dBA) |
| Supported protocols: | DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog |
| Bluetooth Reader | |
| Version | compatible with Bluetooth 5.0 (BLE) |
| Range | (short - typically up to 3m*, long - typically up to 10m*) |
| *distances should serve only as an approximate guide and may vary depending on the phone model and installation environment | |
| Security | RSA-1024 and AES-128 encryption |
| RX sensitivity | up to -93 dBm |
| Mode | touch, tap in app, card |
| Mobile Application Support | |
| Android 6.0 and higher, iOS 12.0 and higher | |
| RFID Card Reader | |
| Supported frequencies | 125 kHz and 13.56 MHz variant |
| Supported card types | card type compatibility depends on Order No. |
| 125 kHz | EM4xxx |
| HID Prox – versions with 125 kHz support and S in Order No. Only | |
| 13.56 MHz | ISO14443A, PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key) |
| reads UID (CSN) and secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology | |
| Secured 13.56 MHz | ISO14443A (MIFARE® DESFire®), PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key), HID SE (Seos, iClass, MIFARE SE) |
| reads secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology | |
| reads PACs ID (HID iClass cards with SIO object) | |
| Mechanical Properties | |
| Frame: | robust zinc cast frame with surface finish (nickel and black color) |
| Operating temperature: | -40°C to +60°C |
| Storage temperature: | -40°C to +70°C |
| Operating relative humidity: | 10%-95% (non-condensing) |
| Dimensions | |
| Wall (surface) mounting frame: | 1 module: 107 (W) x 130 (H) x 28 (D) mm |
| Flush mounting frame: | 1 module: 130 (W) x 153 (H) x 5 (D) mm |
| Flush mounting box (minimum hole): | 1 module: 108 (W) x 131 (H) x 45 (D) mm |
| Weight: | max 0.8 kg |
| Cover rating: | IP54 and IK08 |
