With the 2N® Access Unit RFID 13.56 MHz, you save on cabling and maintenance. No complicated wiring. The reader is also a controller. Simply connect it to an IP network. You connect the lock, exit button and door contact to it directly. The reader also supports NFC, so it offers modern users access with their mobile phone instead of a card.
Interfaces
Power supply:
PoE and/or 12 V/1 A DC
PoE:
802.3af (Class 0–12.95 W)
LAN:
10/100BASE-TX with Auto-MDIX, RJ-45 modular jack
Recommended cabling:
Cat-5e or better
Active switch output:
8 to 12 V DC/max 600 mA
Passive switch:
NO/NC contacts, up to 30 V/1 A AC/DC
Inputs:
2 inputs - in passive/active mode (-30 V to +30 V DC)
OFF = open or Uin> 1.5 V
ON = short-circuit or Uin< 1.5 V
Tamper switch:
native part of the 2N Access Unit 2.0
Audio:
buzzer (97dBA)
Supported protocols:
DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog
RFID Card Reader
Supported frequencies
13.56 MHz
Supported card types
card type compatibility depends on Order No.
13.56 MHz
ISO14443A, PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key)
reads UID (CSN) and secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
Secured 13.56 MHz
ISO14443A (MIFARE® DESFire®), PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key), HID SE (Seos, iClass, MIFARE SE)
reads secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
reads PACs ID (HID iClass cards with SIO object)
Mechanical Properties
Frame:
Robust zinc cast frame with surface finish (nickel and black colour)
Operating temperature:
-40°C to +60°C
Storage temperature:
-40°C to +70°C
Operating relative humidity:
10%-95% (non-condensing)
Dimensions
Wall (surface) mounting frame:
1 module: 107 (W) x 130 (H) x 28 (D) mm
Flush mounting frame:
1 module: 130 (W) x 153 (H) x 5 (D) mm
Flush mounting box (minimum hole):
1 module: 108 (W) x 131 (H) x 45 (D) mm
Weight:
max 0.8 kg
Cover rating:
IP54 and IK08
