Product Construction
Conductor Material: Plain Annealed Copper
Conductor Stranding: Solid, 1/1.00mm
Dielectric Material: Foam Polyethylene (FPE)
Dielectric Diameter: 4.65mm ± 0.05
Screening 1: Overall Aluminium Foil
Screening 1 Coverage: > 100%
Screening 2: Copper Clad Aluminium Wire Braid
Screening 2 Coverage: > 45% ± 3
Sheath Material: Polyvinyl Chloride (PVC)
Sheath Colour: Black
Mechanical Characteristics
Overall Diameter: 6.70mm x 13.5mm ± 0.15mm
Temperature Range: Fixed -15°C to +70°C | Flexing -5 : °C to +70°C
Bend Radius: 10 x Overall Diameter
Weight 87: kg/km
Electrical Characteristics
Inner Conductor DC Resistance: ≤ 26 Ω/km @ 20°C
Outer Conductor DC Resistance: ≤ 63.5 Ω /km @ 20°C
Characteristic Impedance: 75 Ω ± 3
Nominal Capacitance: 49 pF/m ± 3 :
Velocity of Propagation: 82%
