48v GigaBit power supply for use with the UniFi UAP-PRO and UAP-AC. It can also be used with the Ubiquiti Outdoor Instant 802.3af 48v to 16v when connected to other Ubiquiti devices that require 24V or lower input power.
Using 48v supplies allows long ethernet cable runs, typically up to 100 metres at Gigabit Speeds.
This unit can be connected directly to the UniFi UAP-PRO and UAP-AC but must NOT be connected directly to other Ubiquiti devices that are limited to a 24v input maximum. Connecting those devices directly to this unit without the Ubiquiti Outdoor Instant 802.3af 48v to 16v adapter will damage those devices.
Product Features:
Earth grounding/ESD protection
Power LED
Specifications:
Output Voltage: 48VDC @ 0.5A
Input Voltage: 90-260VAC@47-63Hz
Input Current: 0.3A @120VAC, 0.2A @230VAC
Inrush Current: <15A peak @120VAC, <30A peak @230VAC
Efficiency: 70+%
Output Ripple: 1% Max
Switching Frequency: 200kHz
Line Regulation: +/- 0.5%
Load Regulation: +/- 1%
Operating Temperature: -10C to +60 deg C
Storage Temperature: -20 to +85 deg C
Operating Humidity: 5% to 90% non condensing
Size (LxWxH): 91.8 x 59.9 x 33 cm
Weight: 158.5g
AC Connector: IEC-320 C6
Data IN / POE: RJ45 Shielded Socket
80% Current Indicator: Power LED will change colour
Surge Protection: Common Mode Clamping
Protection: 11V Data, 77.5V Power
Max Surge Discharge: 1200A (8/20uS) Power
Peak Pulse Current: 36A (10/1000uS) Data
Shunt Capacitance: <5pf data
Response Time: <1nS
Compliance: UL, EN55022 (CISPR22) class B, Meets CE
